ANDREW
Cable Coaxial Cobre Corrugado 1-5/8 Retardante al fuego
Cable Coaxial Cobre Corrugado 1-5/8 Retardante al fuego
SKU:AVA7RK-50
Agotado
No se pudo cargar la disponibilidad de retiro
Product Classification
Product Type Coaxial wireless cable
Product Brand HELIAX®
Product Series AVA7-50
Ordering Note CommScope® standard product in Asia Pacific | CommScope® standard
product in Europe, the Middle East, and Africa
General Specifications
Flexibility Standard
Jacket Color Black
Performance Note Values typical, guaranteed within 5% | Values typical, unless otherwise
stated
Dimensions
Diameter Over Dielectric 44.45 mm | 1.75 in
Diameter Over Jacket 51.054 mm | 2.01 in
Inner Conductor OD 18.161 mm | 0.715 in
Outer Conductor OD 46.355 mm | 1.825 in
Nominal Size 1-5/8 in
Electrical Specifications
Attenuation, Ambient Temperature 68 °F | 20 °C
Cable Impedance 50 ohm ±1 ohm
Capacitance 72.2 pF/m | 22.007 pF/ft
dc Resistance, Inner Conductor 1.435 ohms/km | 0.437 ohms/kft
dc Resistance, Outer Conductor 0.525 ohms/km | 0.16 ohms/kft
dc Test Voltage 15000 V
*PRECIO POR METRO*
